CC13 Ionization Chamber
Art. N°
Hover to zoom · click to enlarge
Radiation Therapy
CC13 is the standard chamber for clinical use in water phantoms and for measurements of output factors. CC13 is intended for absolute and relative dosimetry of photon, electron, and proton beams in radiotherapy.
Measurements can be performed in air, water phantoms, or solid phantoms.
- Brochure
- /fileadmin/user_upload/products/02_radiation_therapy/CC04/Detector_Brochure.pdf
- Inner dimensions
- Inner dimensions - Active volume: 0.13 cm^3 - Total active length: 5.8 mm - Cylinder length: 2.8 mm - Inner diameter of outer electrode: 6.0 mm - Wall thickness: 0.4 mm (70 mg/cm2 ) - Diameter of inner electrode: 1.0 mm - Length of inner electrode: 3.3 mm
- Used for Workflow
- Commissioning and Annual QA RT, Detectors RT
- Operational characteristics
- Operational characteristics - Polarizing voltage: ±300 V (max. ±500 V) - Typical leakage current: 3 fA - Recommended pre-irradiation: 5 Gy - Typical sensitivity: 3.6 nC/Gy - Guard potential: ±300 V (max. ±500 V) - Temperature range: 15 °C – 35 °C - Relative humidity range: 20 % – 80 %
- Compatible with Machine/Modality/Application
- Small Field Dosimetry
